CrCl<sub>3</sub>预处理和表面活性剂对杨木酶解效率的影响

麦燊怡; 赵宸彪; 张红丹; 谢君

doi:10.11975/j.issn.1002-6819.202210222

CrCl₃预处理和表面活性剂对杨木酶解效率的影响

麦燊怡¹,
赵宸彪¹,
张红丹^1, ,,
谢君^1, ,

华南农业大学生物质工程研究院, 广州 510642

基金项目: 国家重点研发计划（2021YFC2101603, 2021YFC2101602）

详细信息

通讯作者:
张红丹, Email: hdzhang@scau.edu.cn

谢君, Email: xiejun@scau.edu.cn

计量
- 文章访问数: 51
- HTML全文浏览量: 0
- PDF下载量: 59
出版历程
- 收稿日期: 2022-10-26
- 修回日期: 2023-04-22
- 发布日期: 2023-05-30

Effects of CrCl₃ pretreatment and surfactant on improving enzymatic hydrolysis of poplar

Institute of Biomass Engineering, South China Agricultural University, Guangzhou 510642, China

摘要

摘要: 为了探究预处理和表面活性剂对纤维素酶水解效率的影响，该研究以杨木为研究对象，探究了温度对CrCl₃预处理的影响，同时从表面活性剂种类、用量和酶添加量3个方面分析表面活性剂对CrCl₃预处理后样品酶解的促进作用。结果表明：CrCl₃预处理对杨木组分分离有良好的促进效果，经160 ℃预处理后葡萄糖得率达到65.9%。通过结构表征发现预处理后杨木结构完整度降低，提高了纤维素的可接触面，进而提高了酶解效率。在酶解段加入木质素磺酸钙可显著缩短酶解时间，提高酶解效率，同时有效降低纤维素酶用量，最终酶解72h后葡萄糖得率达85.5%，当酶用量为该研究为提升木质纤维原料预处理效率和降低酶解成本提供了一定的理论支持。
- 酶解 /
- 预处理 /
- 木质素 /
- 表面活性剂
Abstract: Biomass energy has the advantages of recyclability and environmental friendliness. Poplar grows rapidly and has a relatively high cellulose content, making it an excellent raw material for the production of biomass energy. However, the cellulose, hemicellulose and lignin of poplar are intertwined to form a dense structure, making it difficult to be hydrolyzed in normal cases. In this work, poplar was pretreated by CrCl₃ as catalyst, the effect of different temperatures was compared, and the optimal pretreatment temperature was determined. Results showed that under the conditions of 0.05 mol/L CrCl₃, solid-liquid ratio of 1/10, pretreatment time of 20min, stirring speed of 300 r/min and pretreatment temperature of 160℃, the components of poplar were effectively separated after pretreatment with CrCl3, while 10.4% lignin and 90.0% hemicellulose removal，and cellulose content increased by 35.6%，hemicellulose and lignin content decreased by 85.5% and 29.9%, respectively. The yield of glucose increased by 568.1% after 72h. In addition, the structure and physical properties of the raw and pretreated poplar were characterized by scanning electron microscope (SEM)、diffraction of X-rays (XRD) and Fourier transform infrared spectrometer (FT-IR). Experimental results indicated that the structure of poplar became loose after CrCl₃ pretreatment, improving the contact surface of cellulose. The crystallinity (CrI) of poplar raw material was 63.84%, then increased to 71.07% after CrCl₃ pretreatment, which was due to the removal of amorphous hemicellulose during pretreatment. In the FT-IR test, the characteristic absorption peak of acetyl groups in hemicellulose was significantly weakened after CrCl₃ pretreatment compared with the raw material, a strong benzene ring characteristic absorption peak was retained at 1510 cm^-1, and the characteristic peak of β-glycosidic bonds still appeared around 898 cm^-1. It is further demonstrated that CrCl₃ pretreatment removed most of hemicellulose and retained the majority of cellulose, which promoted the subsequent enzymatic hydrolysis process，but had less effect on lignin. The enzymatic hydrolysis of pretreated poplar was conducted under the conditions of pH value is 4.8, enzymatic hydrolysis temperature of 50 ℃, shaker speed of 150 r/min, enzyme addition of 20 FPU/g substrate, surfactant dosage of 150mg/g substrate, exploring the promotion effect of surfactant type, dosage and enzyme addition on enzymatic hydrolysis. It was found that the glucose yield of 69.7% was obtained after 24 h with calcium lignosulfonate, which was higher than that after 72 h without additive. Further extending the hydrolysis time to 72 h, the glucose yield reached 85.5%. When the cellulase loading was 5 FPU/g substrate, the glucose yield with calcium lignosulfonate (68.0%) was constant with that when the enzyme dosage was 20 FPU/g substrate without additive. that the addition of calcium lignosulfonate could reduce the hydrolysis time, decrease the dosage of cellulase, and enhance the efficiency of enzymatic hydrolysis. Consequently, the CrCl₃ pretreatment effectively removed the lignin and hemicellulose, while remained cellulose to promote hydrolysis efficiency. Furthermore, the addition of calcium lignosulfonate as a surfactant in the enzymatic hydrolysis also improve hydrolysis efficiency. This study provides some theoretical support for the improvement of pretreatment and the reduction of enzymatic hydrolysis cost.
- enzymatic hydrolysis /
- pretreatment /
- lignocellulose /
- Surfactant

HTML全文

参考文献(32)

[1]	TANG Y, DOU E, JIANG J X, et al. Yield-determining components in high-solid integrated first and second generation bioethanol production from cassava residues, furfual residues and corn[J]. RSC Advances, 2016, 6:50373-50383
[2]	SRIVASTAVA N, RAWAT R, OBEROI H S, et al. A review on fuel ethanol production from lignocellulosic biomass[J]. International Journal of Green Energy, 2015, 12(7-12):949-960.
[3]	MAHMOOD H, MONIRUZZAMAN M, IQBAL T, et al. Recent advances in the pretreatment of lignocellulosic biomass for biofuels and value-added products-ScienceDirect[J]. Current Opinion in Green and Sustainable Chemistry, 2019, 20:18-24.
[4]	MA Y, SHEN Y, LIU Y. State of the art of straw treatment technology:Challenges and solutions forward[J]. Bioresource Technology, 2020, 313:123656.
[5]	王芳,刘晓风,陈伦刚等. 生物质资源能源化与高值利用研究现状及发展前景[J]. 农业工程学报,2021,37(18):219-231. WANG Fang, LIU Xiaofeng, CHEN Lungang, et al. Research status and development prospect of energy and high value utilization of biomass resources (Transactions of the CSAE), 2021, 37(18):219-231. (in Chinese with English abstract)
[6]	SUN S N, SUN S L, CAO X F, et al. The role of pretreatment in improving the enzymatic hydrolysis of lignocellulosic materials[J]. Bioresource Technology, 2016, 199:49-58.
[7]	KUMAR P, BARRETT D M, DELWICHE M J, et al. Methods for pretreatment of lignocellulosic biomass for efficient hydrolysis and biofuel production[J]. Industrial & Engineering Chemistry Research, 2009, 48(8):3713-3729.
[8]	FAN S Y, ZHANG P Y, LI F, et al. A review of lignocellulose change during hydrothermal pretreatment for bioenergy production[J]. Current Organic Chemistry, 2016, 20(26):2799-2809.
[9]	HU F, RAGAUSKAS A, et al. Pretreatment and lignocellulosic chemistry[J]. Bioenergy Research, 2012, 5(4):1043-106.
[10]	PULIGUNDLA P, OH S E, MOK C, et al. Microwave-assisted pretreatment technologies for the conversion of lignocellulosic biomass to sugars and ethanol:a review[J]. Carbon Letters, 2016, 17(1):1-10.
[11]	WU, MIAO, ZHAO, et al. Separation and characterization of lignin obtained by catalytic hydrothermal pretreatment of cotton stalk[J]. Industrial Crops & Products, 2015, 66:123-130.
[12]	CHEN L, RONG C, FU S. Preliminary exploration on pretreatment with metal chlorides and enzymatic hydrolysis of bagasse[J]. Biomass and Bioenergy, 2014, 71:311-317.
[13]	SLUITER A, HAMES B, RUIZ R, et al. Determination of structural carbohydrates and lignin in biomass:NREL/TP-510-42618[R]. Washington:U. S. National Renewable Energy Laboratory (NREL), 2011.
[14]	SEGAL L, CREELY J J, MARTIN A E, et al. An empirical method for estimating the degree of crystallinity of native cellulose using the X-ray diffractometer[J]. Textile Research Journal, 1959, 29(10):786-794.
[15]	任利彤,黎博文,赵思,等. 杨木预水解过程中化学组分的降解行为及P因子调控作用[J]. 林业工程学报,2020,5(2):103-108. REN Litong, LI Bowen, ZHAO Si, et al. Effect of P factor on degradation of poplar chemistry composition during prehydrolysis process[J]. Transactions of the Journal of Forestry Engineering, 2020, 5(2):103-108. (in Chinese with English abstract
[16]	WWA B, ZC A, HW A, et al. Co-production of fermentable glucose, xylose equivalents, and HBS-lignin from sugarcane bagasse through a FeCl3-catalyzed EG/H2O pretreatment[J]. Industrial Crops and Products, 2021, 165:113440.
[17]	KAMIREDDY S R, LI J B, TUCKER M, et al. Effects and mechanism of metal chloride salts on pretreatment and enzymatic digestibility of corn stover[J]. Industrial & Engineering Chemistry Research, 2013, 52(5):1775-1782.
[18]	LIN X, LOU H, QIU X, et al. Effect of sodium dodecyl sulfate and cetyltrimethylammonium bromide catanionic surfactant on the enzymatic hydrolysis of Avicel and corn stover[J]. Cellulose, 2017, 24(2):669-676.
[19]	席琳乔,吴书奇,马春晖. 非离子表面活性剂PEG对棉秆木质纤维素酶解的影响[J]. 农业工程学报,2012,28(23):176-183. XI Linqiao, WU Shuqi, MA Chunhui. Effect of nonionic surfactant PEG on lignocellulose enzymatic hydrolysis of cotton stal[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2012, 28(23):176-183. (in Chinese with English abstract
[20]	FANG Z F, LIU K L, CHEN F S, et al. Cationic surfactant-assisted microwave-NaOH pretreatment for enhancing enzymatic hydrolysis and fermentable sugar yield from peanut shells[J]. Bioresources, 2014, 9(1):1290-1302.
[21]	ZHANG Y, XU X, ZHANG Y, et al. Effect of adding surfactant for transforming lignocellulose into fermentable sugars during biocatalysing[J]. Biotechnology and Bioprocess Engineering, 2011, 16(5):930-936.
[22]	GONG Z, YANG G, SONG J, et al. Understanding the promoting effect of non-catalytic protein on enzymatic hydrolysis efficiency of lignocelluloses[J]. Bioresour Bioprocess, 2021, 8:9.
[23]	ZHANG J, XIE J, ZHANG H. Sodium hydroxide catalytic ethanol pretreatment and surfactant on the enzymatic saccharification of sugarcane bagasse[J]. Bioresour Technol, 2021, 319:124171.
[24]	TANG W, WU X, HUANG C, et al. Natural surfactant-aided dilute sulfuric acid pretreatment of waste wheat straw to enhance enzymatic hydrolysis efficiency[J]. Bioresour Technol, 2021, 324:124651.
[25]	ZHANG H, HUANG S, WEI W, et al. Investigation of alkaline hydrogen peroxide pretreatment and Tween 80 to enhance enzymatic hydrolysis of sugarcane bagasse[J]. Biotechnol Biofuels, 2019, 12:107.
[26]	DONG, M., WANG, S., XU, F. et al. Pretreatment of sweet sorghum straw and its enzymatic digestion:insight into the structural changes and visualization of hydrolysis process[J]. Biotechnol Biofuels, 2019:12:276.
[27]	TAO X, ZHANG P, ZHANG G, et al. Thermo-carbide slag pretreatment of turfgrass pruning:Physical-chemical structure changes, reducing sugar production, and enzymatic hydrolysis kinetics[J]. Energy Conversion and Management, 2018, 155:169-174.
[28]	ZHAO C, SHAO Q, MA Z, et al. Physical and chemical characterizations of corn stalk resulting from hydrogen peroxide presoaking prior to ammonia fiber expansion pretreatment[J]. Industrial Crops and Products, 2016, 83:86-93.
[29]	董倩,唐松,徐禄江,等. 乙二醇-氯化铁预处理对棉秆酶水解效率的影响[J]. 农业工程学报,2021,37(14):213-220. DONG Qian, TANG Song, XU Lujiang, et al. Effects of ethylene glycol-ferric chloride pretreatment on the enzymatic hydrolysis of cotton stalks[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2021, 37(14):213-220. (in Chinese with English abstract
[30]	ZHANG J, MA X, YU J, et al. The effects of four different pretreatments on enzymatic hydrolysis of sweet sorghum bagasse[J]. Bioresource Technology, 2011, 102(6):4585-4589.
[31]	WANG S, LV M, YANG J, et al. Effects and mechanism of metal ions on enzymatic hydrolysis of wheat straw after pretreatment[J]. Bioresources, 2018, 13(2):2617-2631.
[32]	李祥,陆子琦,浦译文,等. 温度-压力解耦条件下汽爆玉米秸秆物化作用及酶解效果[J]. 农业工程学报,2022,38(3):239-246. LI Xiang, LU Ziqi, PU Yiwen, et al. Physicochemical properties and enzymatic digestibility of steam-exploded maize stalk under temperature-pressure decoupling[J]. Transactions of the Chinese Society of Agricultural Engineering (Transactions of the CSAE), 2022, 38(3):239-246. (in Chinese with English abstract)
